基本特性
|
|
|
4G
|
LTE Cat4
|
|
尺寸(mm)
|
32.0×29.0×2.6
|
|
封裝
|
144pin
LCC+LGA
|
|
頻段(MHz)
|
-EU(EMEA/韓國/泰國/印度)
|
FDD
LTE: B1/B3/B5/B7/B8/B20
TDD LTE: B38/B40/B41
WCDMA: B1/B5/B8
GSM: B3/B8
|
|
-AU(適用于拉丁美洲/澳大利亞/新西蘭/日本/臺灣)
|
FDD
LTE: B1/B2/B3/B4/B5/B7/B8/B28
TDD LTE: B40
WCDMA: B1/B2/B5/B8
GSM: B2/B3/B5/B8
|
|
-VA(北美)
|
FDD
LTE: B2/B4/B12/B13
WCDMA: B2/B4/B5
|
|
-CN(中國)
|
FDD
LTE: B1/B3/B8
TDD LTE: B38/B39/B40/B41
WCDMA: B1/B8
TD-SCDMA: B34/39
CDMA 2000 1X/EVDO: BC0
GSM: B3/B8
|
|
重量(g)
|
5.3
|
|
工作溫度(℃)
|
-40
~ +85
|
|
|
|
|
|
數據傳輸
|
|
|
|
LTE
速率(Mbps)
|
FDD LTE:Max
150(DL)/50(UL)
TDD LTE:Max 130(DL)/35(UL)
|
|
DC-HSPA+
速率(Mbps)
|
Max
42(DL)/5.76(UL)
|
|
WCDMA
速率(Kbps)
|
Max
384(DL)/384(UL)
|
|
TD-SCDMA
速率(Mbps)
|
Max
4.2(DL)/2.2(UL)
|
|
EDGE
速率(Kbps)
|
Max
236.8(DL)/236.8(UL)
|
|
GPRS
速率(Kbps)
|
Max 85.6(DL)/85.6(UL)
|
|
EVDO
速率(Mbps)
|
Max
3.1(DL)/1.8(UL)（-CN）
|
|
SMS
|
●
|
|
CSD
|
●
|
|
網絡協議
|
IPv4/IPv6/TCP/UDP/PPP/FTP/HTTP/HTTPS/NTP/PING/SSL
|
|
|
|
|
|
硬件接口
|
|
|
|
SIM
|
1.8V/3.0V
|
|
UART
|
●
|
|
USB
|
●
|
|
I2C
|
●
|
|
PCM
|
●
|
|
休眠/喚醒控制
|
●
|
|
狀態指示
|
●
|
|
ADC
|
●
|
|
GPIO
|
●
|
|
天線
|
主天線，分集接收天線
|
|
|
|
|
|
特殊功能
|
|
|
|
eCall
|
●
|
|
DTMF
|
●
|
|
QMI/Rmnet
|
●
|
|
FFS
|
●
|
|
RIL
Driver
|
Android 4.0 or later
|
|
NDIS
|
Windows
XP/7/10
|
|
ECM
|
Linux
2.6 or later
|
|
Gobinet
|
Linux
2.6 or later
|
|
Linux qml wwan
|
Linux
2.6 or later
|
|
USB
驅動
|
Windows
7
Linux 2.6 or later,
Android 2.3/4.0/4.2/4.4/5.0/6.0
|
|
SIM
熱插拔
|
●
|
|
固件更新
|
通過USB接口
|
|
|
|
|
|
|
|
|
電氣參數
|
|
|
|
供電輸入
|
3.3V~4.3V(typ.
3.8V)
|
|
功耗
|
關機
|
20μA
|
|
睡眠
|
3mA
|
|
待機
|
22mA
|
|
|
|
|
|
推薦應用領域
|
|
|
應用領域
|
公網對講、移動支付、車聯網、CPE、多媒體終端、無線手持終端、智能家居、工業應用等
|
